0.5KW-2.2KW

Drive control mode:V/F & vector

Input voltage range:380/220V±15%

Input frequency range:40~65Hz

Output voltage range:0~Rated input voltage

Output frequency range:0~600Hz

Programmable analog input:0-10V input 0 / 4 ~ 20mA input

Relay output:2 relay output states (below 5.5KW default is1 relay )

Analog output:0-10V;4—20ma (below 5.5KW default is0-10V )

Overload capacity:150% rated current 60s 180% rated current 10s

Speed regulation ratio:1:100

Carrier frequency wave:3-15.0kHz
